Experienced
Versatile
Responsive
With our experience and versatility and with the ability to respond when urgent orders are required, we continuously work closely with our customers to develop ideas and products from inception to production.
We realise the importance of quality and reliability in today’s marketplace and continuously adapt to the ever-changing demands required from the engineering industry.
Importantly, we offer input into the design of the products to ensure that the products are cost-effective to manufacture.
We have excellent relationships with local and national metal finishers. This enables us to supply quality finished parts anodised, plated or painted.
We welcome all types of enquiries and can supply you a competitive quotation with no obligation.
Plant List
Click the + to view machine information
Machining Centres
| Machining Name | Capacity | Other Specs |
|---|---|---|
| Zayer 3000 BF3 | Capacity 2650 mm x 1004 mm x 989 mm (XYZ) | Speeds range 28 - 1800 rpm, Spindle taper 50 ISO, Distance between slots 125 mm, Table surface 3000 mm x 700 mm, Heidenhain 415 control. |
| Haas Super Mini Mill (x2) | Capacity 406 mm x 305 mm x 254 mm (XYZ) | 15,000 rpm vector spindle drive, 4th axis drive, 914 mm x 305 mm table size, 10 tool capacity, Rigid tapping. |
| Haas Vertical VF-1 | Capacity 506 mm x 406 mm x 508 mm (XYZ) | 10HP twin speed geared head - 7500 rpm, Fully integrated 4th axis providing true interpolation and helical cutting, Processing speed 1000 blocks per second, Full graphical display. |
| Haas Vertical VF-3 | Capacity 1016 mm x 508 mm x 635 mm | 15HP twin speed geared head - 7500 rpm, Fully integrated 4th axis providing true interpolation and helical cutting, Processing speed 1000 blocks per second, Full graphical display. |
| Haas Vertical VF-4 | Capacity 1270 mm x 508 mm x 635 mm | 15HP twin speed geared head - 7500 rpm, Fully integrated 4th axis providing true interpolation and helical cutting, Processing speed 1000 blocks per second, Full graphical display. |
| Haas Vertical VF-0E Machining Centre | Capacity 762 mm x 406 mm x 508 mm | 10HP spindle motor - 7500 rpm, Fully integrated 4th axis providing true interpolation and helical cutting, Processing speed 1000 blocks per second. |
| DAHLI 1020 Vertical Machining Centre | Capacity 1000 mm x 450 mm x 508 mm | 10HP spindle motor - 7500 rpm, Fanuc 6MB control, Full graphical display. |
| Johnford DMC3100S | Capacity 3100 mm x 1750 mm x 950 mm (XYZ) | Speeds range 35 - 6000 rpm - 26Kw, Spindle taper 50 ISO, Distance between slots 125 mm, Table surface 3000 mm x 1500 mm, Fanuc 0i - MD with graphics. |
| Doosan HM63H Twin Pallet Horizontal Machining Centre | Twin pallet - pallet size 630 mm x 630 mm, Full B axis .001 increments, X axis travel 1050 mm, Y axis travel 1070 mm, Z axis travel 940 mm, Spindle motor AC22/25, 60 tool automatic toolchanger, Fanuc 18i MB control. | |
| Anayak Siere HVM-3300 Universal Machining Centre | X axis travel 2700 mm, Y axis travel 1000 mm, Z axis travel 1000 mm, Spindle motor AC22/25, 20 tool automatic toolchanger, Heidenhain 426 control, Processing speed 1000 blocks per second. |
CNC Turning
| Machine Name | chuck | Other Specs |
|---|---|---|
| Doosan Turning Centre S700M | 28.0" chuck | 50 hp 3 step gear box, 910 mm diameter swing, 1880 mm between centres, 700 mm maximum cutting diameter, 1730 mm maximum cutting length, 125 mm bar capacity, Full graphical display. |
| Haas Turning Centre SL-30 | 12" chuck | 30 hp vector drive, 76 mm dia. magazine bar feed, 990 mm between centres, 431 mm maximum cutting diameter, 865 mm maximum cutting length, Full graphical display. |
| Haas Turning Centre SL-20 | 8.3" chuck | 20 hp vector drive, 23" diameter swing, 610 mm between centres, 262 mm maximum cutting diameter, 508 mm maximum cutting length, Full graphical display. |
| Alpha Plus UCL | Computerised cycling and control, DNC link to Alpha Link Offline programming, 13" diameter swing, 1000 mm between centres. | |
| Doosan S390 L CNC Lathe | Distance between centres 1200 mm, Max turning diameter 390 mm, Max bar diameter through spindle 66 mm, Fanuc 18T control. | |
| Doosan S310 CNC Lathe | Distance between centres 450 mm, Max turning diameter 310 mm, Max bar diameter through spindle 66 mm, Fanuc 18T control. |
Conventional Turning
| Machine Name | Swing | Other Specs |
|---|---|---|
| Colchester Triumph 2000 Centre Lathe | 22" swing | 50" between centres, Hepworth hydraulic copying for profiling and taper threading |
| Colchester Mascot 1600 Centre Lathe | 28" swing | 3" through spindle, 80" between centres. |
Conventional Milling
| Machine Name | Capacity | Other Specs |
|---|---|---|
| 3 x Bridgeport Universal Turret Mill | 13" x 33" x 26" capacity | Acu-rite DRO 200M with pitch calculator and edge finder, Slotting head, 90" drilling attachment. |
Inspection - Fully Equipped Inspection Department
| Machine Name | Measuring Range | Other Specs |
|---|---|---|
| Mitutoyo C604-10 | Measuring range X 1000 mm, Y 450 mm, Z 600 mm | Coordinate measuring machine, QCT-2000 measuring software, Renishaw probe system. |
| Starrett HE400 Optical Projector | Measuring Range X 254 mm x 100 mm | 16" screen projection area |
